Cast Steel Globe Valve


Cast Steel Globe Valve

Specifications

Material Cast Steel
Certification ISI Certified
Power Hydraulic
Structure Double Half Shaft
Features Blow-Out-Proof, Casting Approved, Durable
Port Size 0.1mm-5cm, 2cm-50cm
Technic Gear Operated
Number Of Way 2way

We are engaged in manufacturing, exporting and supplying of Cast Steel Globe Valve. We understand that various applications of the industries depend on Cast Steel Globe Valve, therefore we provide quality-tested Globe Valve to the customers. Our Globe Valve has flawless design structure. Customers can get Cast Steel Globe Valve from us at market leading rates.

Features

  • OS & Type, Bolted bonnet.Plug Type Disc.
  • Design Std. BS 1873 /ANSI 16.34 .
  • Face to Face Dimension as per B 16.10.
  • Testing as per BS 6755-1/ EN ISO 12266-1.
  • Valves with back seat arrangement.
  • Flange Drilling as per ANSI B16.5 RF Serrated / Buttweld ends as per B16.25


On Request

  • Parabolic plug for linear characteristics.
  • Guided & Soft seat plug .
  • Locking arrangement.
  • Gear/Electrical Actuator.
  • NACE as per MR-01-75.
  • Stellited Hard face.
  • For low temp & Cryogenic Service as per BS 6364.
  • Jacketed valves.

Yes! I am interested

Submit Your Requirement


Materials of Construction

Part Name Material Option
Body ASTM A216 WCB/A217 WC6, WC9, C5, C12/A351 CF8, CF8M, CF3, CF3M/A352 LCB/A890 DUPLEX
Bonnet ASTM A216 WCB/A217 WC6, WC9, C5, C12/A351 CF8, CF8M, CF3, CF3M/A352 LCB/A890 DUPLEX
Plug ASTM A216 WCB/A217 WC6, WC9, C5, C12/A351 CF8, CF8M, CF3, CF3M/A352 LCB/A890 DUPLEX
Seat Rings ASTM A216 WCB/A217 WC6, WC9, C5, C12/A351 CF8, CF8M, CF3, CF3M/A352 LCB/A890 DUPLEX
Stem ASTM A276 SS410/SS 304/SS 304L/SS 316/SS 316L/DULPEX
Gland ASTM A276 SS410/SS 304/SS 304L/SS 316/SS 316L/DULPEX
Gland Flange ASTM A216 WCB/A217 WC6, WC9, C5, C12/A351 CF8, CF8M, CF3, CF3M/A352 LCB/A890 DUPLEX
Yoke Bush ASTM A439 D2/ASTM A473 416 /S.G.IRON
Gland Packing GRAFOIL / PTFE
Bonnet Gasket SPIRAL WOUND SS304/304L/316/316L/321+GRAFOIL/PTFE
Eye Bolt / Nut ASTM A193 B7 A194 2H
Body Stud ASTM A193 B7/B7M/B8/B8M /B16/ASTM A320/L7
Body Nut ASTM A194 2H/2HM/ 8/ 8M /ASTM A320/ 7
Hand Wheel S.G. Iron / Malleable Iron / Carbon Steel
