Cast Steel Butterfly Valve


Cast Steel Butterfly Valve

Specifications

Sizes 40mm to 600mm
Pressure Rating PN 10 & PN 16 (MAX).
Operating Temprature 40oC to 200oC
Flanges ANSI #125/150,PN10, PN16 & BS 10 TABLE D&E.
Material Cast Steel
Type Butterfly

Our Cast Steel Butterfly Valve is made using premium metals and alloys. We provide Butterfly Valve in different sizes. Butterfly Valve that we offer has a compact design and needs low maintenance. In addition to this, our Cast Steel Butterfly is available at market leading rates.

Features

  • Suitable for mounting between all standard
  • Flanges are ANSI #125/150,PN10, PN16 & BS 10 TABLE D&E.
  • Operating Temprature : 40oC to 200oC
  • Constrution Type : Center disc design with replaceble rubber seat.
  • Design std BS EN 593 ( Replace by BS 5155 ). IS 13095 & API 609.
  • Testing std BS EN 12266-1/ BS 6755-1 ).
  • Face to Face as per BS EN 558 & ISO 5752.
  • Pressure Rating : PN 10 & PN 16 (MAX).
  • Sizes : 40mm to 600mm
  • Excellent flow control in quarter turn operation.
  • Compact, space saving design.
  • Bi-directional 100% tight shut off.
  • Low weight, low maintenance, long service life
  • Both shafts mounted in bearing supports for easy operating torques.
  • Gasket packing not required to install between flanges

Yes! I am interested

Submit Your Requirement


Materials of Construction

Part Name Material Option
Body CI GG25, DI GGG40, A217 WCB A351 CF8/CF8M , AB2.
Disc DI GGG40, A351 CF8/CF8M , AB2.
Seat / Sleeve EPDM, NITRILE, VITON, NEOPRENE,
Shaft ASTM A276 SS410/SS 304/SS 316 / SS
Hand Lever Carbon Steel

Garph


Garph
